MSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard

MSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard
  • Status: In Stock
  • Brand: MSI
  • Model: MAG B860M MORTAR WIFI
অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে |

Key Features

    • Model: MAG B860M MORTAR WIFI
    • Supported CPU: Intel Core Ultra Processors (Series 2), LGA 1851
    • Supported RAM: 4x DDR5, Dual Channel 9200+ MT/s (OC), Max 256GB
    • Graphics Output: 1x HDMI, 1x DisplayPort, 1x Type-C DisplayPort
    • Features: 3x M.2 Slot, 1x 5Gbps LAN, Intel Killer Wi-Fi 7, Bluetooth 5.4
    General Feature
    BrandMSI
    ModelMAG B860M MORTAR WIFI
    MemoryMemory Support 9066 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 9200+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports Intel POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM
    Others 4x EZ Debug LED 1x EZ Memory Detection LED
    Processor
    ChipsetINTEL B860
    Memory Specifications
    Number of Memory Slots4x UDIMM
    Memory TypeDDR5
    Connectivity
    HDMI1x HDMI 2.1 with FRL
    Storage
    Storage Type 3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
    Graphics
    Graphics Model 1x HDMI Support HDMI 2.1 with FRL, maximum resolution of 8K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz 1x Type-C DisplayPort Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
    Technical Info
    Audio 1x Front Audio (JAUD)
    Network & Connection
    Lan Intel Killer E5000 5Gbps LAN
    Physical Attributes
    USB4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front)
    Warranty Information
    Warranty03 Years

    MSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard

    The MSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard is a powerful and reliable motherboard designed to support the latest Intel Core Ultra Processors (Series 2) with an LGA 1851 socket. This motherboard is built for gamers, professionals, and power users who need high-speed performance, excellent connectivity, and efficient cooling in a compact mATX form factor.

    One of the standout features of the MSI MAG B860M MORTAR WIFI is its support for DDR5 memory. It offers four DIMM slots, allowing up to 256GB of RAM with speeds ranging from 8800 to 6400 MT/s (OC). This high-speed memory capability enhances multitasking, gaming, and professional workloads, ensuring seamless operation even under heavy loads.

    For storage, the motherboard is equipped with three M.2 slots, supporting PCIe Gen 4 storage. These NVMe SSD slots provide lightning-fast data transfer speeds, reducing load times for games, applications, and large files. Whether you're working with high-resolution media files, gaming, or running demanding applications, this storage solution ensures optimal performance.

    The MSI MAG B860M MORTAR WIFI features multiple display output options, including 1x HDMI, 1x DisplayPort, and 1x Type-C DisplayPort, providing excellent flexibility for high-resolution monitors. This makes it an ideal choice for gamers, content creators, and professionals who need multiple screen setups for their workflow.

    For networking, this motherboard includes a Realtek 8126 5Gbps LAN port, delivering ultra-fast wired internet speeds. Additionally, it supports Wi-Fi 7, ensuring the best wireless connectivity available. With low latency and fast speeds, Wi-Fi 7 is ideal for gaming, streaming, and video conferencing. The motherboard also supports Bluetooth 5.4, enabling seamless connection with wireless peripherals like keyboards, mice, and headphones.

    Designed with high-quality components and a robust cooling system, the MSI MAG B860M MORTAR WIFI ensures stable performance under extreme conditions. The enhanced heatsink design and advanced PCB layout help maintain lower temperatures, improving overall system longevity. This motherboard is built for durability and reliability, making it an excellent choice for both casual and professional users.

    Buying Suggestion from Dear IT Solution

    At Dear IT Solution, we offer the MSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard at the best price in Bangladesh. We ensure that our customers receive high-quality products with reliable after-sales service. When you purchase from us, you benefit from secure transactions, fast delivery, and expert support to assist you with any queries.

    Whether you are building a new PC or upgrading your system, the MSI MAG B860M MORTAR WIFI is a top-tier choice for those looking for performance, connectivity, and durability. Place your order today at Dear IT Solution and experience the best quality product insured in Bangladesh
